電動皮卡 Configuration of Electric Pickup-second-generation
Remark:"●"Available "—"Not Available EV Luxury 5seats
（Left hand drive）EV Luxury 2seats
（Left hand drive）EV Luxury 5seats（Right hand drive） EV Luxury 2seats（Right hand drive） 電動兩驅短軸五座豪華版
（左舵）電動兩驅短軸二座豪華版
（左舵）電動兩驅短軸五座豪華版
（右舵）電動兩驅短軸二座豪華版
（右舵）
MODEL DYQ1032BEV1-H DYQ1033BEV1-H DYQ1032BEV1R-H DYQ1033BEV1R-H 基本參數 Basic Parameter
變速箱 Transmission / / / / 整車長*寬*高 Vehicle Overall Dimensions (mm) 5330*1870*1864 5330*1870*1864 5330*1870*1864 5330*1870*1864 貨箱長*寬*高 Packing box Overall Dimensions (mm) 1575*1610*530 2380*1499*519 1575*1610*530 2380*1499*519 最高車速(km/h) Maximum Speed 120 120 120 120 續航里程（NEDC） Endurance mileage (NEDC) 275 275 275 275 實測離地間隙 Ground Clearance(mm) 210 210 210 210 車身 Car body
軸距 Wheel Base(mm) 3100 3100 3100 3100 前輪距 Front Wheel Base (mm) 1580 1580 1580 1580 后輪距 Rear Wheel Base (mm) 1580 1580 1580 1580 整備質量 Curb Mass (kg) 2000 1900 2000 1900 車身結構 Vechicle Type PICKUP PICKUP PICKUP PICKUP 車門數(個) Door 4 2 4 2 座位數(個) Seat 5 2 5 2 電池容量（kWh） Battery capacity (kWh) 60/65kWh 60/65kWh 60/65kWh 60/65kWh 電池品牌 Battery brand CATL CATL CATL CATL 電池種類 Battery type Lithium iron phosphate Lithium iron phosphate Lithium iron phosphate Lithium iron phosphate 充電標準 Charging standard Chinese standard, Japanese standard, European standard Chinese standard, Japanese standard, European standard Chinese standard, Japanese standard, European standard Chinese standard, Japanese standard, European standard 快充充滿電時間 Fast charging and full charge time (h) 0.75（20%-80%） 0.75（20%-80%） 0.75（20%-80%） 0.75（20%-80%） 電機 Motor
額定/峰值功率 Rated/peak power(KW) 65/130 65/130 65/130 65/130 額定轉速 Rated speed（RPM） 4000 4000 4000 4000 最高轉速 Maximum speed 12000 12000 12000 12000 額定轉矩 Rated torque 120 120 120 120 最大扭矩(N·m) Maximum torque (N · m) 330N.m 330N.m 330N.m 330N.m 變速箱 TRANSMISSION
擋位個數 Speed / / / / 變速箱類型 Type / / / / 底盤轉向 Chassis
驅動方式 Driving Method 2WD 2WD 2WD 2WD 前懸架類型 Front Suspension Double Wishbone Independent Suspension Double Wishbone Independent Suspension Double Wishbone Independent Suspension Double Wishbone Independent Suspension 后懸架類型 Rear Suspension Leaf spring suspension Leaf spring suspension Leaf spring suspension Leaf spring suspension 助力類型 Steering Hydraulic Power Steering Hydraulic Power Steering Hydraulic Power Steering Hydraulic Power Steering 車體結構 Body Structure PICKUP PICKUP PICKUP PICKUP 車輪制動 Wheel Brake
前制動器類型 Front Brake Type Ventilated Disc Ventilated Disc Ventilated Disc Ventilated Disc 后制動器類型 Rear Brake Type Drum Drum Drum Drum 駐車制動類型 Parking Brake Type Hand Hand Hand Hand 前輪胎規格 Front Tyre Size 245/70R17 245/70R17 245/70R17 245/70R17 后輪胎規格 Rear Tyre Size 245/70R17 245/70R17 245/70R17 245/70R17 備胎規格 Spare Tyre no Spare Tyre no Spare Tyre no Spare Tyre no Spare Tyre 輪胎花紋 Tread pattern Road tire Road tire Road tire Road tire 安全裝備 Active/Passive Safety
主/副駕駛座安全氣囊 Dual Airbags ● ● ● ● 安全帶未系提示 Seatbelt Unfastening Warning System ● ● ● ● 車內中控鎖 Central Locking ● ● ● ● 遙控鑰匙 Remote Key ● ● ● ● 上坡輔助 Uphill assistance ● ● ● ● 碰撞后車門自動解鎖 Automatic door unlocking after collision ● ● ● ● 行車自動落鎖 Automatic locking of driving ● ● ● ● 操控配置 Control Equipment
ABS防抱死 ABS ● ● ● ● 制動力分配(EBD/CBC等) EBD ● ● ● ● ESC電子防滑系統 ESC / / / / 定速巡航 Fixed-speed cruise / / / / 外部配置 External Equipment
鋁合金輪圈 Alum-Alloy Wheel ● ● ● ● 差速鎖 differential lock / / / / 上車踏板 Boarding pedal ● ● ● ● 貨箱防刮涂層 Anti scratch coating for container ● ● ● ● 防滾架 The roll cage ● ● ● ● 大后保險杠 Large rear bumper ● ● ● ● 小后保險杠 Small rear bumper 選裝 選裝 選裝 選裝 內部配置 Internal Equipment
方向盤 Steering Wheel Leather Leather Leather Leather 方向盤調節 Steering Wheel Adjusting Type Up and Down Up and Down Up and Down Up and Down 多功能方向盤 Steering Wheel w/Audio and Bluetooth ● ● ● ● 倒車視頻影像 Visual Imaging System ● ● ● ● 倒車?yán)走_(dá) Reverse Sensor ● ● ● ● 眼鏡盒 glasses case - - - - 內后視鏡 Interior rearview mirror - - - - 主副駕上儲物盒 Upper storage box of driver and passenger ● ● ● ● 點煙器和煙灰缸 Cigarette lighter and ashtray ● ● ● ● 行車電腦顯示屏 ECU Monitor ● ● ● ● 一鍵啟動 One touch start ● ● ● ● 無匙進入 Keyless entry ● ● ● ● 座椅配置 Seat Equipment
座椅材質 Seat Material PU Leather PU Leather PU Leather PU Leather 主駕電動座椅 Main driving electric seat ― ― ― ― 駕駛座座椅調節 Driver's seat adjustment Manual 4-way adjustment Manual 4-way adjustment Manual 4-way adjustment Manual 4-way adjustment 副駕駛座座椅調節 Front passenger seat adjustment Manual 4-way adjustment Manual 4-way adjustment Manual 4-way adjustment Manual 4-way adjustment 多媒體配置 Multimedia Equipment
GPS導航系統 GPS System ● ● ● ● 中控臺彩色大屏 Colourful Screen ● ● ● ● 藍牙/車載電話 Bluetooth/Car telephone ● ● ● ● 外接音源接口 Sound Source Connector USB+AUX USB+AUX USB+AUX USB+AUX 揚聲器數量 Speaker 4 2 4 2 燈光配置 Lighting Equipment
近光燈 Dipped Headlight Halogen Halogen Halogen Halogen 遠光燈 Full Beam Headlight Halogen Halogen Halogen Halogen 前霧燈 Front Lamp ● ● ● ● 大燈高度可調 Electric Height-adjustable Headlamps ● ● ● ● 頂部照明 Top lighting ● ● ● ● 門燈 Door lamp ● ● ● ● 玻璃/后視鏡 Window/Rear View Mirror
前/后電動車窗 Front/Rear Window Electric Electric Electric Electric 折疊后視鏡 Folding Rearview ― ― ― ― 后視鏡電動調節 Electrical Control Rear View Mirror ● ● ● ● 空調/冰箱 Air Condition
空調控制方式 Electric Control Air Conditioning electric electric electric electric
